FS Curtis Masterline "ML" Series - When You Absolutely Need Heavy Duty Industrial Reliability

Masterline is the most robust, heavy-duty reciprocating air compressor in the FS Curtis lineup. The perfect combination of quality components and efficient design make the ML Series rugged, affordable and smart. Because every model is built tough to last a lifetime in demanding working conditions, the ML Series is an outstanding alternative to splash lubricated reciprocating compressors and small rotary compressors. Choose higher quality. Choose superior durability. Choose ML Series pressure lubricated air compressors.

Whats the difference between the ML15 and the ML15+?

• The ML15 features the D97 compressors pump.  While the ML15+ utilizes the larger C89 pump which turns a little slower yet creates around 10% more CFM.

Standard Features:

• Centro-Ring pressure lubrication
• 100% casting-iron cylinders, cylinder heads, connecting rods, and crankshaft
• Factory oil filled
• Magnetic motor starter (60Hz)
• Automatic Start-Stop control
• ASME approved air receiver
• Manual condensate tank drain valve
• Dial read-out pressure gauge
• UL approved pressure switch
• ASME approved discharge valve air service valve
• Metal intake filter-silencers
• Dynamically balanced flywheel
• OSHA approved totally enclosed belt guard
• Slow V-belt drive
• NEMA-1 control panel
• Premium Efficiency Motors (3-phase only)
• Tank shut off valve
• Dual Control ML5-ML15(D97) with pilot valve
