FS-Curtis NXB18 Ultrapack – 25 HP Rotary Screw Air Compressor with Integrated Dryer
Product Description
Industrial-Scale Air with Integrated Drying
The FS-Curtis NXB18 Ultrapack delivers powerful, production-level compressed air with built-in air treatment in one compact, factory-engineered system. Designed for manufacturing facilities, large automotive service centers, woodworking production environments, and fabrication shops, this 25 HP rotary screw compressor provides consistent airflow and clean, dry air in a single integrated package.
With up to 114 CFM at 100 PSI, the NXB18 Ultrapack is engineered for facilities running multiple machines, air tools, and production processes simultaneously.
Integrated Refrigerated Dryer & Prefilter
The Ultrapack configuration includes a factory-installed refrigerated dryer and prefilter to ensure clean, moisture-free compressed air.
Benefits include:
-
Simplified installation
-
Reduced floor space requirements
-
Fewer downstream components
-
Lower risk of leaks
-
Protection for CNC equipment, paint systems, and air tools
-
Improved overall system reliability
This all-in-one configuration reduces total installed cost and streamlines your compressed air system.
Airflow Performance (CFM by Pressure)
The NXB18 Ultrapack is available in multiple pressure configurations:
-
114 CFM @ 100 PSI
-
100 CFM @ 125 PSI
-
92 CFM @ 150 PSI
-
84 CFM @ 175 PSI
This range allows you to properly match the compressor to your facility’s operating pressure and demand.
Optional iCommand Touch Controller Upgrade
Upgrade to the iCommand Touch controller for enhanced system control and visibility.
Features include:
-
Full-color touchscreen interface
-
Real-time pressure and temperature monitoring
-
Maintenance reminders
-
Fault history and diagnostics
-
Performance trending and tracking
-
Enhanced compressor protection
This upgrade is ideal for production facilities where uptime and preventative maintenance are critical.
Continuous-Duty Rotary Screw Performance
Engineered for 100% continuous duty, the NXB18 delivers smooth, pulsation-free airflow. Unlike large piston compressors that aggressively cycle, rotary screw technology provides:
Ideal applications include:
-
Manufacturing and assembly lines
-
Large woodworking and cabinet production shops
-
Multi-bay automotive facilities
-
Fabrication and processing environments
-
Paint booths and finishing operations
NXGEN Extended Warranty Protection
All NX Series compressors are supported by the NXGEN Extended Warranty Program when properly registered and maintained using genuine FS-Curtis parts and lubricants:
This industry-leading coverage reflects the durability and engineering built into every NX platform compressor.
Why Buy from Compressed Air Advisors Online?
Compressed Air Advisors Online is America’s choice for compressed air solutions. We provide nationwide expertise to ensure your voltage, pressure, and controller configuration are properly matched to your operation.
We help you size it correctly, configure it properly, and support it long term.
